Noctua 120mm NF-A12x25 PWM 2000RPM Fan
In stock
SKU
NF-A12x25-PWM
$73.00
Maximize cooling efficiency with the NF-A12x25 Fan. Precision-engineered for top performance in airflow and silence. Shop now for a cooler system!
| Feature | Details |
|---|---|
| Size | 120 x 120 x 25 mm |
| Mounting Hole Spacing | 105 x 105 mm |
| Connector & Pin-Configuration | 4-pin PWM |
| Cable Length | 20cm + 30cm NA-EC1 extension cable |
| Bearing | SSO2 |
| Blade Geometry | A-Series with Flow Acceleration Channels |
| Frame Technology | AAO (Advanced Acoustic Optimisation) |
| Material | Sterrox® LCP |
| Rotational Speed (+/- 10%) | 2000 RPM |
| Rotational Speed with L.N.A. (+/- 10%) | 1700 RPM |
| Min. Rotational Speed @ 20% PWM (+/-20%) | 450 RPM |
| Airflow | 102.1 m³/h |
| Airflow with L.N.A. | 84.5 m³/h |
| Acoustical Noise | 22.6 dB(A) |
| Acoustical Noise with L.N.A. | 18.8 dB(A) |
| Static Pressure | 2.34 mm H₂O |
| Static Pressure with L.N.A. | 1.65 mm H₂O |
| Input Power (Typical) | 1.2 W |
| Input Power (Max.) | 1.68 W |
| Input Current (Typical) | 0.1 A |
| Max. Input Current | 0.14 A |
| Operating Voltage | 12 V |
| Voltage PWM Signal | 5 V |
| MTTF | > 150,000 h |
| Scope of Delivery | Low-Noise Adaptor (L.N.A.), 4-pin y-cable, 30cm extension cable, NA-AV2 anti-vibration mounts, Anti-vibration gasket for water cooling radiators, Fan screws |
